Crawler  Mobile Screening

Cone type tire mobile crushing station

Crawler type mobile screening Station is made with advanced design concept and scientific production process.

Feeding particle size:<200mm
Production capacity:50-400T/H
Scope Of Application:Widely used in industries such as resource recovery, aggregate production, coal mine production, venue waste, construction industry, iron ore screening and other industries
Handling Materials:Limestone, granite, marble, basalt, iron ore, river pebbles, shale, blue stone, coal, cobblestone, construction waste, etc

inquiry now

Leave Message

  • 01
    Answer customer questions professionally
  • 02
    Combined with the actual configuration plan
  • 03
    Regular return visit and testing
Get the production plan for free

Product Introduction

Crawler type mobile screening Station is made with advanced design concept and scientific production process. It is effectively used for screening requirements of different materials in combination with adjustable screening angle, amplitude and vibration intensity. With high screening efficiency and large output, it is suitable for various screening operations such as heavy, medium and fine screening. It is widely used in mining, coal, building materials, sand and gravel, metallurgy, chemical industry and other fields. According to the different particle sizes and materials of finished products, we provide customers with a variety of screen surfaces, models and uses of crawler mobile screening equipment.



Performance advantages


The transition is convenient and widely used. The crawler is mobile, and it is applicable to a wide range of working conditions. The transition is very convenient. Under any terrain conditions, this equipment can reach any position on the work site and be put into production quickly.


The equipment has a large capacity receiving hopper, which can effectively buffer materials and ensure continuous and stable material input.


The whole machine adopts hydraulic folding technology, and the transportation status and working status can be quickly switched. Reduce the time waste of transit transportation.


The high strength steel frame structure is adopted to improve the service life and strength of the equipment, with extraordinary durability.


The compact structure design enables the equipment to perfectly adapt to various working conditions and production sites.


The number of screen faces is optional, which can be customized flexibly according to different sizes and types of finished products.

Technical Parameters

Item MC-S6018 MC-S7020
Capacity(t/h) 85-350 100-350
screen model YZS1860 YZS2070
Screen size(mm) 1800×6000 2000×7000
Main belt model(mm) 1000×11000 1200×11000
Whole machine power(KW) 50 65
Transport size(L*W*H)


14500×3500×3850 14500×3800×3850
Weight(T) 33 45

Cone type tire mobile crushing station Station factory

Our company is a professional manufacturer of crushing equipment. The company’s senior engineers tailor-made for each customer, scientifically select equipment and do not rework, to ensure that the equipment selected for customers is reasonable and affordable, with stable operation and high efficiency.

Free customized professional and reasonable solution

Oretek provides you with a full set of mine equipment and services. If you are interested in our company and products, you are welcome to come to the factory to inspect. We will arrange for you to visit the crushing site to intuitively experience the quality of the high quality product!
